Description
Length 48' Width 102" Weight 9795 lbs. +/-3% Unit Description TS-5 Floor Aluminum with Center Tie Down Track Nailing Strips Four (4), Apitong Chain Tiedowns 10 Pair, 6" Oval, Removable Front/Rear Member Aluminum Side Rail Aluminum Pipe Spools Double Winch Track Full Length with No Breaks, Roadside Sliding Winches 12 Toolbox Two (2) 60"x24"x22" Cam Lock w/ SS Doors Add. Receptacle ISO 7-Way Side Rail Lights Thirteen (13) per Side, LED Rear Lights (3) Stop/Tail, (5) Clearance & (15) Add. Markers Mud Flap Brackets Behind Front & Rear Axle # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Intraax 30K Suspension Setting 10' 2" Spread, Set at Rearmost Position Lift Axle Front Axle, Both Manual & Electric Electric Dumpvalve Rear Axle - Wired to Center Pin of Aux 7-Way Manual Dumpvalve Yes Tire Brand Michelin XZE2 Tire Size 11R24.5 Wheels Aluminum, Outside Wheels Polished King Pin Setting 30" Cross Member Center 12" Coil Package Full Coil Package with 12 Extra Cross Members Landing Gear Jost, Two-Speed, Aluminum Housing Paint Black Weight Ratings 70,000 lbs. in 10', 60,000 lbs. in 4' Scalamatic Lift Axle Wired to Red Wire of ISO 7-Way Additional Wiring & Plugs for Rear Markers 4-Way Receptacle at Rear
Features
...
