Description
*FET INCLUDED* Length 45' 4" Width 102" Top Deck Length 11' 6" Main Deck Length 24' Main Deck Height 24" Loaded Rear Deck Length 9'10" Weight 17,000 Lbs. +/- 3% Flat Body Floor 1 1/2" Apitong (Mesh Center) Ramps 24" Steel Spring Assist Front Ramps Side Rail Perimiter Beam - Steel Outriggers 24" Centers (Locks both in & out position) D-Rings ROTO style. (6) siderail, (1) Bolster Toolbox 1st & 2nd Section of Deck, Exp. Metal, 2 Doors Rear Lights (2) Stop/Tail, (3) Clearance Strobe Lights Amber Strobe with Battery Flag Holders One Set at Rear Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Cush Suspension Setting 54" Axle Spacing Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Steel UnderFrame King Pin Setting 15" Cross Member Center 10" Deep, 18" Centers Paint Black Weight Ratings 35 Ton 90" Swing Clearance Wheel Covers Four (4) Section Recessed Bucket Plate at Rear Traction Bars on Front & Rear Slope Boomwell 4S/2M ABS Spring Brakes 20,280 GAWR
Features
...
