Description
Length 50' 8" Width 102" Top Deck Length 11' 6" Main Deck Length 24' Main Deck Height 24" Loaded Rear Deck Length 14' 4" Weight 19,500 Lbs. +/-3% Flat Body Floor 1 1/2" Apitong Beavertail Beavertail with Hydrualic Ramps Ramps 36" Wood Filled Spring Assist Front Ramps Side Rail Perimiter Beam - Steel Outriggers 24" Centers (Locks both in & out position) D-Rings ROTO style. (6) Siderail, (1) Bolster, (1) Beaver Rear Lights (2) Stop/Tail, (3) Clearance Strobe Lights Amber Strobe with Battery Flag Holders One Set at Rear Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Cush Suspension Setting 54" Axle Spacing Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Steel UnderFrame King Pin Setting 15" Cross Member Center 10" Deep, 18" Centers Paint Black Weight Ratings 35 Ton
