Description
Cincinnati, OH Length 53' Width 102" Height 13' 6" Unit Description Plate Van Inside Width 101" Scuff to Scuff (101-1/4" Panel to Panel) Inside Height 110" Door Opening 110" Tall, 99" Wide Sides .313 Composite Plate (10 year warranty) Color White Type Posts Series "A" logistics posts Post Spacing 48" Side Scuff 6" Corr. Steel above Integral Alum, 12" Total Side Lining Plate Nose Lining .180" Ridge OGRE Full Height Internal Bulkhead 10 ga x 12" Smooth Steel Rear Doors 1/2" Composite PPW Galvanized Panels Hinges Five per Door Roof Aluminum Roof Bows 1" Deep Galvanized Anti-Snag on 16"/24" Rear Frame GALVANIZED Bumper GALVANIZED, Reinforced for Dock-Lock Rubber Dock Bumpers One Pair Recessed Between Lights Van Floor 1 3/8" Oak with Three 5/16" Screws per Board Threshold Plate 27" Galvanized Steel # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson HKANT40K, SureLok & QuikDraw Suspension Setting 49" Sliding Tandem, 216" Slide Rails Tire Size 295/75R22.5 Wheels Steel, Powder Coated White King Pin Setting 36" Cross Member Center 12" Landing Gear Jost, Two-Speed Comments -Reverse Corner Radius Fasteners so that Fastener Head in on the Outside and Collar on the Inside -ABS: Bendix 2S-1M with SR-5 Spring Brake Release Valve
Features
...
